Name: GSM Senior Telecare / GSM Security Alarm System
Brand: Beilai Tech. Co., Ltd.
SKU: K3
Availability: InStock
Rating: 5 (1 reviews)

No.K3

The K3 is a versatile GSM alarm panel and senior telecare system, featuring SOS calls, fall detection, intrusion alerts, and environmental monitoring (CO, fire, water). It supports wireless sensors, remote control, SMS commands, and temperature alerts. Ideal for homes, offices, and elderly care, it ensures security and emergency response with GSM connectivity and customizable settings.

Request Pricing

Description

The K3 is a brevity, fashion and neat design GSM Security Alarm System, it is not only a security alarm system but also a senior telecare system. The User can send SMS text to control it and received SMS text from it while something happened.

The K3 includes multi-functions and high reliability, it is special for Residential areas, business area, commercial area, office, factory, industrial area, senior emergency call, senior daily activation and communication, and other Varity applications. It integrated high performance GSM Module and MCU inside, and with innovative and experienced functions and features to meet the required and potential demands in the worldwide markets.

When it used as a GSM Security Alarm system, the user can call in to Arm/Stay operation with a free charge from its phone. and plus different wireless detectors to protect its assets.

When it used as the senior telecare system, it can be used as a GSM Emergency call system, and also can dial and send SMS to preset numbers while: Fall Down, Push SOS Button, Hasn't got up bed in time, carbon monoxide leak, or intrusion.

At this period, the aging trend is very serious in all countries, and lots of seniors living alone. They are need urgently help in sometime, also worry about death while sleep or fall down and nobody know it.

The LCD can display the current time, what sensor activated, and current indoor temperature.

Key Features

Brevity,Fashion,Neat design;
LCD display current time, which detector activated, indoor current temperature;
Supports temperature higher or lower than preset value alert function;
Big SOS Button easy to push it;
High quality of voice communication;
Supports 6 preset call numbers for SMS or Call or both;
Supports monitoring senior get up bed in time or not;
Supports wireless fall down detector;
Supports total 17 wireless detectors or SOS buttons;
Supports free charge to Arm/Stay operation with authorized user phone numbers;
Inbuilt rechargeable battery inside;
Easy to use, no need to train;
Easy to installation, can put on desk or onto wall.

Typical Application Scenarios

Home Security – Detects intrusions (doors/windows) and triggers alarms with SMS alerts.
Senior Care – Monitors falls, SOS calls, and bed-exit times for elderly safety.
Fire/Gas Safety – Alerts for smoke, CO leaks, or water leakage via SMS/calls.
Remote Control – Arm/disarm via SMS, phone calls, or wireless remote.
Temperature Monitoring – Alerts for high/low temperature thresholds.
24/7 Emergency – Silent/audible alarms for panic buttons (e.g., necklaces).
Business Protection – Secures offices/stores with wired/wireless sensors.
Customizable Alerts – Programmable SMS content and zone-specific responses.

Technical Specifications

Rated Voltage: 12VDC 1 A (12V~14VDC)
Standby Consumption: 30~35mA (Not charging battery)
Working Consumption: 400mA(Siren working)
Working temperature: -10ć̚+60ć Storage temperature: -20ć̚+60ć Relative humidity: 10-90%, No condensation
GSM frequency: 850/900/1800/1900MHz
Communication protocol: GSM PHASE 2/2+ (include data service)
Wired Zones: 1 (Dry Contact, NC or NO)
Wireless Encode: Learning code, compatibles fixed encode.
Wireless Zone: 17 (can accept one learning code wireless detector in each zone, and accept unlimited PT2262/2272 fixed code wireless detectors in each zone)
Remote Control: 3
Wireless Frequency: 433Mhz
Wireless Distance: 100m in open air.
Backup Rechargable Battery: 3.7V@900~1200mAH lithium batteries
Net Weight: 0.50Kg

Packaging

1 x GSM Alarm Panel
1 x Wireless PIR Motion Detector
1 x Wireless Door Contact
2 x Remote Control
1 x AC/DC Adaptor
1 x User Manual
