Name: 8-channel Dry Contact Digital Input Module
Brand: Beilai Tech. Co., Ltd.
SKU: Y13
Availability: InStock
Rating: 5 (1 reviews)

8-channel Dry Contact Digital Input Module

No.Y13

The Y13 digital input module is part of the Y series I/O modules designed for use with IOy and ARMxy series products. It provides 8 digital input channels (DI1 to DI8) for capturing digital signals from field devices. Widely used in industrial automation and control systems, the Y13 ensures reliable data acquisition through robust isolation technology, effectively reducing signal interference and enhancing overall system safety and stability.

Technical Specifications

Name	Parameter	Description
Power Supply	Operating Voltage	Internal Voltage
Power Supply	Power Consumption	0.4W
Digital Input	Channel	8 Channels
	Triggering Method	Dry contact
	Logic level	Logic 1: Shorted with common terminal Logic 0: Disconnected from common terminal
	Isolation protection	2KVrms
Certifications	EMC	IEC 61000-4-2 (ESD) Level 3
		IEC 61000-4-4 (EFT) Level 3
		IEC 61000-4-5 (Surge)Level 3

We use Cookie to improve your online experience. By continuing browsing this website, we assume you agree our use of Cookie.

No.	Name	Model	Channel	Signal Type
1	8-channel digital input module	Y11	8	Low-level trigger
2	8-channel digital input module	Y12	8	High-level trigger
3	8-channel digital input module	Y13	8	Dry contact

8-channel Dry Contact Digital Input Module

Technical Specifications

Model Selection

Connection Example
