Y37 IEPE Input Module is one of the optional Y-series I/O modules available in products such as the IOy series and ARMxy series.
This module features 4 input channels: CH1, CH2, CH3, and CH4. It is a signal acquisition module specifically designed for IEPE sensors. The module can collect signals such as acceleration, pressure, and sound pressure.
Y37 IEPE Input Module is one of the optional Y-series I/O modules available in products such as the IOy series and ARMxy series.
This module features 4 input channels: CH1, CH2, CH3, and CH4. It is a signal acquisition module specifically designed for IEPE sensors. The module can collect signals such as acceleration, pressure, and sound pressure.
Each channel is capable of converting the high-impedance charge signal from the sensor into a low-noise, low-impedance voltage signal and transmits it with 24-bit resolution.
Technical Specifications
|
Name |
Parameter |
Description |
|
Power Supply |
Operating Voltage |
Internal Voltage |
|
Power Consumption |
0.12W |
|
|
IEPE Input |
Channels |
4CH |
|
Signal Input Range |
±10V |
|
|
Coupling |
AC Coupling |
|
|
Excitation Voltage |
23V (Minimum) |
|
|
Excitation Current |
3.5mA |
|
|
Resolution |
24-bit |
|
|
Bandwidth |
0.6Hz~20kHz |
|
|
Data Rate |
144KSPS Wideband Filter per Channel |
|
|
Signal-to-Noise Ratio (SNR) |
＞100dB@1kHz |
|
|
Clock Frequency |
27MHz |
|
|
Gain |
0.4V/V |
|
|
Input Impedance |
＞250kΩ |
|
|
Certifications |
EMC |
IEC 61000-4-2 (ESD) Level 3 |
|
IEC 61000-4-4 (EFT) Level 3 |
||
|
IEC 61000-4-5 (Surge)Level 3 |
Connection Example
