BA190 BACnet/IP Edge I/O: Redefining the New Benchmark for Intelligent Building HVAC Systems
The launch of Beilai Technology's BA190 BACnet/IP Edge I/O module provides a brand-new intelligent solution for building HVAC systems, directly replacing the traditional structure of DDC + I/O + gateway. Through deep integration of edge computing and IoT technologies, it achieves a leapfrog upgrade for HVAC systems from "passive control" to "active optimization."
Native BACnet/IP support, seamlessly connecting with mainstream building automation systems
Compatible with Modbus TCP/RTU, enabling integration with third-party devices
Optional MQTT & OPC UA protocols for direct IoT cloud connectivity
Dual Ethernet ports support daisy-chain topology, reducing wiring complexity
BLRAT remote tool support, allowing remote upgrades, debugging, and configuration anytime
16-channel high-precision analog inputs (0-10V/4-20mA)
8-channel relay outputs (16A/250VAC)
4-channel PWM voltage regulation outputs, supporting inverter control
Built-in temperature & humidity sensor (±0.5°C accuracy)
Local execution of PID control algorithms, with response times <50ms
Supports load forecasting & energy-saving optimization algorithms
Data preprocessing reduces 90% of redundant data transmission
Offline data buffering ensures data integrity
Beilai Technology’s BA190 Edge I/O module is redefining the standards for intelligent HVAC systems in buildings. By embedding data acquisition, real-time control, and intelligent analytics at the edge, it not only solves the issues of slow response and low energy efficiency in traditional systems but also pioneers a closed-loop control model of "sensing-analysis-decision-optimization." Against the backdrop of carbon neutrality goals, the BA190 will serve as a key technological enabler for energy conservation and emission reduction in the construction sector, driving the high-quality development of green and smart buildings.
